Electronic lock S4A-2052 TTLock

Key Features

1. Smart Control via Bluetooth 5.0: Safe and convenient keyless door opening – all you need is a smartphone with the TTLock app (Android/iOS). You can remotely manage users, assign access, view history, and configure lock settings in real time.

2. IC card support (MIFARE 13.56 MHz): Add up to 1,000 user cards – ideal for homes, offices, or short-term rentals. Various authorization modes: single, time-based, recurring, and permanent – ​​all configurable through the app.

3. Create and manage eKeys: Send electronic keys to family, friends, or guests. You can set their validity (temporary, single-use, cyclical) and send them remotely, for example, via text message, email, or instant messaging app.

4. Auto-locking and Passage Mode: The lock can automatically lock after a specified period of time. Set the door to "passage" mode, which keeps the door open during selected hours (e.g., during office hours).

5. In-app history view and notifications: Gain complete visibility into who opened your door and when. The app records every operation, allowing you to review and export it (e.g., to a CSV file). Real-time notifications of unauthorized access attempts.

6. User and Administrator Management: Add multiple users and administrators with varying levels of permissions. Perfect for businesses, families, and tenant management – ​​complete access control.

7. Low battery warnings and emergency mode: When the battery voltage drops below 4.7V, the lock sounds an audible signal. Emergency unlocking is available at very low voltage.

8. Easy, no-drill installation: The lock mounts on the inside of the door – no damage to the door leaf or drilling required. Ideal for wooden, PVC, or composite doors up to 60mm thick.

9. Modern and minimalist design: The lock remains invisible from the outside, preserving the aesthetics of the door. The elegant, compact housing complements any interior – from classic to modern.

10. Safe unlocking from the inside – compliance with evacuation standards: The lock allows manual unlocking of the door, ensuring the ability to quickly leave the room in emergency situations , such as fire or power failure.

TTLock system in practice

On the outside of the door is the WK2 keypad – you enter the code, and the door opens. Instead of searching for keys, you can enter your assigned PIN in one move, opening the door in person or granting remote access.

The user can also use the R1 remote control , which allows the door to be opened without having to approach it – e.g. from a car, reception desk or apartment upstairs.

On the inside of the door there is an RX2052 lock , which can be opened manually with a knob, IC card or via the app.

To make the system work even faster and fully remotely, you can supplement it with the TTLock Wi-Fi gateway , which enables instant data synchronization between the application and devices – without the need for physical proximity.

All system components – lock, keypad, remote control and Wi-Fi gateway – are available in our range and can be freely combined to create a configuration tailored to your needs.

You can also expand the set with devices compatible with the TTLock app, such as wireless keypads, door locks, electronic padlocks, cabinet locks, and door inserts.

Versatile opening

1. Contactless card/key fob/sticker/remote control - Quick and convenient unlocking using a contactless card, key fob or sticker.

2. TTLock application - Convenient and quick remote opening of the lock via the application with one click.

3. Knob - Possibility of manually opening the lock, without the need to use additional functions.

Thanks to these various options, each user can choose the most suitable method of opening the lock, which increases the comfort and safety of use.

Proximity cards/key rings/stickers/remote controls are available in our assortment.

An electric lock in an access control system can be used in various facilities in many ways.

Here are some examples of how to use an electric lock:

1. Offices and corporate spaces

• Access control to selected zones – e.g. server rooms, archives or departments with limited access.
• User management from the application level – the ability to assign temporary or cyclical permissions to employees.
• Event log – full history of door openings available to the administrator.

2. Houses and apartments

• Keyless security – access only for authorized persons via telephone, IC card or remote control.
• The perfect solution for short-term rentals – quickly generate e-keys for Airbnb guests with a time limit.

The lock will also find its use in schools, shops and other facilities .

Technical specifications

• Operating voltage: 4.5 – 9 V
• Standby current: 329 µA (with Wi-Fi active)
• Operating current: < 200 mA
• Power supply: 4 x AA batteries (not included)
• Card Type: MIFARE M1: IC Card (13.56MHz)
• Memory: 1000 cards
• Operating temperature: −20℃ ~ +70℃
• Water resistance: None
• Remote unlocking: Yes (TTLock app)
• Supported systems: Android 4.3+ / iOS 7.0+
• Dimensions: 183.4 × 71.4 × 30 mm/ 111 m x 31 mm

The set includes

• 1x RX2052 electronic lock
• 1x Access Sticker
• 2x Access Cards
• 1x Set of mounting accessories
• 1x User Manual

The Polish manual is available as an electronic download in the attachment. You can find it above or below our product description .
