Electromagnetic lock EL-600S
We present to you the Spreest electric magnetic lock. This product is designed to protect homes and businesses, ensuring high quality and reliability. Thanks to its innovative solutions and robust construction, this lock guarantees security and ease of use.
Key Features
1. Durable and solid body: aluminum alloy housing + stainless steel core guarantee long service life even in intensively used facilities.
2. Safe Mode: NO Model: The lock is locked when powered and unlocks when the power is off, meeting the requirements of evacuation and fire protection systems.
3. Versatile: Suitable for wooden, glass, metal and anti-burglary doors.
4. No moving mechanical parts: This makes it very durable.
5. Environmental resistance: operation at temperatures from -10 °C to +55 °C and humidity ≤ 90% RH; for outdoor installation, additional sealing is sufficient.
6. High holding force: 280 kg, which allows you to secure both residential and commercial doors with high traffic.
Description of the lock operation
The EL-600S electromagnetic lock consists of an electromagnet that is installed in the door frame and a metal plate screwed to the door leaf.
When the electromagnet coil is energized, the metal plate is attracted with great force, securing the entrance. The maximum door pressure at which the electromagnet attracts the metal plate is 280 kg .
Electromagnetic locks, such as the EL-600S , are typically used where safety regulations require the door to open after a power failure in the control system and in places where it is not possible to install traditional locks.
Technical specifications
- Material: Aluminum alloy shell + low carbon and stainless steel core and plate
- Operating voltage: DC 12 V
- Operating current: 500 mA
- Holding force: 280 kg
- Operating mode: NO (the lock is locked when powered and unlocks after a power failure)
- Wiring: red wire – positive pole (+), black wire – negative pole (–)
- Operating temperature range: –10 °C to +55 °C
- Operating humidity: ≤ 90% RH
- Installation conditions: wooden, steel, aluminum, glass doors (with or without frame); additional protection against moisture is required when installing outdoors
- Dimensions : 250 × 48 × 27 mm/ 180 × 38 × 12 mm
- Weight: 1.8 kg
The set includes
- 1x Electromagnetic lock EL-600S
- 1x Mounting accessories
- 1x User Manual
The Polish manual is available as an electronic download in the attachment. You can find it above or below our product description .
