Video intercom JD-S1Vi05A-7W Black 4-wire - 1x Screen + 1x Station
Lowest price in the 30 days before the discount: 342,09 zł
Introducing the Spreest brand video intercom – a simple and modern solution that will make it easier for you to control access to your home or business.
With a large, colorful, clear 7" screen and a 105° wide-angle camera, you can clearly see the entire gate, even at night.
Thanks to two-way communication, you can conveniently talk to your guests while standing at the screen. You can easily open the electric strike using RFID cards and key fobs – no need for a key!
Using the screen, you can effortlessly open the gate and wicket.
The durable outdoor station casing with an IP55 rating guarantees operation in difficult weather conditions.
Easy installation and the possibility of expansion to up to 3 monitors make the set ideal for any home. The ready-to-use kit ensures quick installation, and with the set, you receive full post-purchase support.
Key features
- Large, clear 7" screen - Easily recognize faces and details, color display, touch buttons, volume and brightness control.
- 105° wide-angle camera - The lens covers the entire monitored entrance.
- Two-way communication - Conveniently talk to your guests while standing at the screen.
- Gate and wicket control - Open the gate and wicket directly from the screen, with two independent controllable relays.
- Night mode - Recognize guests even in complete darkness, thanks to discreet infrared illumination.
- Melody customization - Adjust the melodies and volume of the video intercom to your taste, with a mute option.
- Expandable to up to 3 monitors - perfect view on every floor or in the office, managed by one set.
- Waterproof - The outdoor unit is resistant to rain, dust, and vandalism, designed to work in all conditions.
- Quick and simple installation - Clear markings, 4-wire technology, full installation manual. Wall mount, dedicated power supply, RFID tags, and complete wiring included.
Installation
The entire system operates on a four-wire line (power + audio-video). Simply run it from the main unit to the outdoor panels and – if necessary – further to additional monitors.
- Additional indoor units (1) – you can connect up to two additional monitors to one 4-wire central unit, to have a view and control, e.g., on an upper floor or in an office.
- Main unit (2) – 7″ screen from which you talk to guests, open the wicket/gate, and set up the system.
- Gate output (3) – a separate relay allows you to open the driveway gate or garage door with one touch.
- Electric strikes (4) – locks mounted in the wicket; each powered by its outdoor panel, and one of them can also be released directly from the monitor screen.
- Outdoor units (5) – units at the wicket with a camera and RFID reader; each has the ability to connect an electric strike and an exit button
- Exit buttons (6) – mounted on the property side, they allow residents to open the wicket themselves when leaving.
Remember about correct wiring polarity and using a cable of at least 4 × 0.75 mm² RVV – then the image and sound will remain clear even over longer distances. Expansion is just as simple: you add another monitor or another outdoor panel.
Technical Specification
Outdoor panel
- Sensor / resolution: 1/3″ CMOS, 1 MP (800 TVL)
- Lens / angle: 3.7 mm pinhole, 105° (D-FOV)
- Night illumination: IR diodes 940 nm
- Audio: two-way, speaker + microphone
- Lock control: 2 relays (NO/NC)
- RFID opening: 125 kHz ID cards, 5 pieces included
- Waterproof rating: IP65
- Power supply: from monitor (DC 12–18 V)
- Operating temperature: –40 °C … +70 °C
- Dimensions: 135 x 63 x 39 mm
Indoor monitor
- Display / resolution: 7″ LCD, 1024×600
- Audio: two-way, built-in microphone and speaker
- Ringtones: 15 melodies, volume control
- Additional functions: "Do Not Disturb" mode, OSD menu
- Set support: max 3 indoor monitors
- Power supply: DC 12–18 V power adapter (included)
- Operating temperature: –20 °C … +70 °C
- Dimensions: 195 x 120 x 15 mm
Set includes
- 1x JD-S1Vi05A-7 Black Video Intercom Indoor Station
- 1x Power adapter
- 1x Mounting accessories
- 1x JD-S1Vi05A-7W Video Intercom Outdoor Station
- 1x Mounting accessories
- 5x RFID 125 kHz key fobs
Instruction manual in Polish is available in electronic version in the downloadable attachment. You can find it below or above our product description.
