We present the Spreest video intercom – a simple and modern solution that will help you control the entrance to your home or business.
With a large, colorful and clear 7” screen and a 105° wide-angle camera, you can see the entire gate clearly, even at night .
Thanks to two-way communication , you can comfortably speak with your guests while standing at the screen. You can conveniently open the electric strike using RFID cards and key fobs – without having to use a key!
Using the screen, you can easily open the gate and wicket door.
The durable, IP55 rated outdoor station housing guarantees operation in harsh weather conditions.
Easy assembly and the ability to expand to three monitors make the set ideal for any home. The ready-made kit ensures quick installation, and the set comes with full post-purchase support .
Key Features
- Large, clear 7" screen - Easily recognize faces and details, color display, touch buttons, volume and brightness control.
- Wide camera angle 105° - The lens covers the entire monitored entrance.
- Two-way communication - You can comfortably talk to your guests while standing at the screen.
- Controlling the gate and door – You can open the gate and door directly from the screen, two independent controllable relays.
- Night mode – recognize visitors even in complete darkness thanks to discreet infrared lighting.
- Customizing melodies – You can adjust the melodies and volume of the video intercom to your taste, with the option of complete muting.
- Expandable to 3 monitors – perfect viewing on every floor or office, managed by one set.
- Waterproof – The outdoor unit is resistant to rain, dust and vandalism, designed to work in all conditions.
- Quick and easy installation – Clear markings, 4-wire technology, full assembly instructions. The set includes a wall mount, a dedicated power supply, RFID chips and a complete set of cables.
Installation
The entire system operates on a four-wire line (power + audio/video). Simply run it from the main unit to the external panels and, if necessary, on to additional monitors.
- Additional indoor units (1) – you can connect up to two additional monitors to one 4-wire control unit to have an overview and control, e.g. on the first floor or in the office.
- Main unit (2) – 7″ screen from which you talk to the visitor, open the gate and set up the system.
- Gate output (3) – a separate relay allows you to open the entrance gate or garage door with one touch.
- Electric strikes (4) – locks installed in the gate; each powered by its own external panel, and you can also release one of them directly from the monitor screen.
- External units (5) – units at the gate with a camera and RFID reader; each has the option of connecting an electric strike and an exit button
- Exit buttons (6) – mounted on the side of the property, they allow household members to open the gate themselves when leaving.
Be sure to observe correct wire polarity and use at least 4 × 0.75 mm² RVV cable – this will ensure clear image and sound even over longer distances. Expansion is equally simple: add another monitor or external panel.
Technical specifications
External panel
- Sensor / resolution: 1/3″ CMOS, 1 MP (800 TVL)
- Lens/angle: 3.7mm pinhole, 105° (D-FOV)
- Night lighting: 940 nm IR LEDs
- Audio: two-way, speaker + microphone
- Lock control: 2 relays (NO/NC)
- RFID Opening: 125 kHz ID cards, 5 pieces per set
- Waterproof class: IP65
- Power supply: from monitor (DC 12-18 V)
- Operating temperature: –40 °C … +70 °C
- Dimensions: 135 x 63 x 39 mm
Internal monitor
- Display/resolution: 7″ LCD, 1024×600
- Audio: two-way, built-in microphone and speaker
- Ringtones: 15 melodies, volume control
- Additional functions: Do Not Disturb mode, OSD menu
- Set support: max 3 internal monitors
- Power supply: DC 12-18V power adapter (included)
- Operating temperature: –20 °C … +70 °C
- Dimensions: 195 x 120 x 15 mm
The set includes
- 1x Video doorbell indoor station JD-S1Vi05A-7 White
- 1x Power Supply
- 1x Mounting accessories
- 1x Video intercom outdoor station JD-S1Vi05A-7W
- 1x Mounting accessories
- 5x RFID 125 kHz chip
The Polish manual is available as an electronic download in the attachment. You can find it above or below our product description .
