RTAG-3 RFID 13.56 MHz Access Key Fob
RFID 13.56 MHz key fob by Spreest compliant with MIFARE Classic 1K GEN1 standard. Designed for access control systems, intercoms, time and attendance systems, and all devices operating in 13.56 MHz technology.
Enables full data copying from MIFARE Classic 1K cards and key fobs and other 13.56 MHz media with 1024 bytes capacity, including MIFARE S50.
The key fob also allows for independent programming of all sectors.
Key features
- Media copying: MIFARE Classic 1K, MIFARE S50, other 13.56 MHz / 1024 bytes
- Programming: full editing of sectors, blocks, and keys
- UID change: ability to set an identification number so that the key fob is recognized by the system as the original medium
- Communication standard: ISO/IEC 14443A
- Format: ABS plastic key fob with metal ring
- Application: access systems, time and attendance systems, identification, intercoms
Technical specification
-
Standard: MIFARE Classic 1K GEN1
-
Memory: 1024 bytes (16 sectors)
-
Frequency: 13.56 MHz
-
Key support: Key A / Key B
-
UID changeable: yes (GEN1)
-
Copy compatibility: MIFARE Classic 1K, MIFARE S50, other 13.56 MHz 1024 bytes media
-
Protocol: ISO/IEC 14443A
-
Dimensions: 40 × 32 × 4 mm
-
Material: ABS + metal ring
-
Color: blue
The set includes
-
1x RTAG-3 RFID 13.56 MHz access key fob
