MXH3 RFID duplicator 13.56MHz + 125kHz
Discover a new level of convenience and security with the RFID MXH3 IC ID duplicator from Spreest. This advanced device combines functionality and ease of use, allowing for easy copying and reading of RFID cards.
Our duplicator supports a wide range of RFID cards with frequencies of 125KHz and 13.56MHz. Whether you need to copy an office access card, a club card, or even an ID card, our device will handle the task effortlessly.
Key Features
1. CCID and PC/SC Compliance: Enables seamless integration with a wide range of systems.
2. Support for IC/ID Dual Frequency Replication: Supports cards with 125KHz and 13.56MHz frequencies, ensuring versatility.
3. Driver-Free: No need to install additional software; the device is ready to use right out of the box.
4. Full-Speed USB Interface: Fast and reliable data transmission.
5. Two-Color LED Light Indicator: Red light indicates standby mode for the code to be copied, and green light indicates programming mode for units with a previously entered code.
6. Built-in Buzzer: Audible notifications for operation status.
7. Support for a Wide Range of Cards: ID125K, 8800, 5200, 4305, 5577, 8265 cards, UID, FUID, CUID, UFUID, and most semi-encrypted and fully encrypted IC cards.
8. Additional software for more efficient work with RFID cards and keyfobs.
Technical specifications
- Interface: USB-C
- Operating voltage: 5 V DC
- Operating current: 200mA
- Standby current: 50mA
- Operating frequency: 125KHz / 13.56 MHz
- Supported operating systems: Windows (does not support Linux, Mac)
- Dimensions: 108 mm (L) x 68 mm (W) x 12 mm (H)
How to use the reader?
- Connection: Connect the device to your computer using a USB cable.
- Software: View the device drive and open the "NFC_USA.url" file, which will redirect you to the software page.
Reading and writing 125KHz RFID cards:
- Place the card on the reader and press the "read" button in the software.
- The software will scan and display the card number.
- Place the writable ID on the reader and press the "write" button in the software.
Reading and writing 13.56MHz IC cards:
- Place the card on the reader and press "card number" or "start decoding" in the software.
- Place the writable UID on the reader and press "write card" in the software.
Additional software
The Spreest duplicator comes with intuitive computer software that facilitates managing card reading and writing. The program has an easy-to-use interface that allows for seamless switching between operating modes (LF Card, HF Card, Monitor Card). The user can quickly read, write, and monitor the status of RFID cards, making working with the device extremely efficient. The software automatically recognizes the connected device, allowing for immediate operation without the need for additional configuration.
Set includes
- 1x RFID MXH3 IC ID Duplicator
- 1x Data transfer cable for the device
Instructions in Polish in electronic version available as a downloadable attachment. You can find it below or above our product description.
