Surface-mounted exit button EB-1406
The EB-1406 touchless exit button from Spreest is the perfect choice for places where comfort, safety and durability are important.
Thanks to advanced infrared technology, IP68 waterproofness and a robust metal housing, it will work well both indoors and outdoors – even in the most demanding conditions.
Key Features
1. Touchless infrared operation – a hygienic and modern solution without physical contact.
2. IP68 waterproof – fully resistant to water and dust, ideal for outdoor use and humid rooms.
3. Adjustable detection range (3–20 cm) – precise adjustment to environmental conditions.
4. Possibility to set the activation time (0.3–30 s) – full control over the opening time.
5. Solid zinc alloy housing – durability, aesthetics and resistance to mechanical damage.
6. Multifunctional NO/NC/COM contacts – compatibility with various access control systems.
7. LED indicators – blue (standby) and green (motion response) for clear operating status.
8. Lifespan of 100,000 cycles – long-lasting and failure-free operation.
IP68 waterproof
It is characterized by exceptional waterproofness in accordance with the IP68 class, which means full resistance to dust and long-term immersion in water .
This makes it ideal for places exposed to harsh weather conditions, moisture or intensive use – both inside and outside buildings .
The robust metal housing made of zinc alloy ensures durability and reliable operation for a long time even in the most demanding environments.
Customization according to your needs
The button offers the ability to adjust the closing time and the motion detection range , which allows its operation to be perfectly tailored to the individual needs of the user.
The detection range can be easily adjusted from 3 to 15 cm , ensuring accurate and reliable gesture response .
Additionally, the ability to adjust the activation (closing) time increases the comfort of use and integration with various access control systems available in our range .
It is an intelligent solution that combines convenience, security and flexibility.
Technical specifications
- Power supply: DC 12V
- Contact load capacity: 1A at 36V DC
- Output contact: NO / NC / COM
- Mechanical life: 100,000 cycles
- Surface mount: Zinc alloy
- Type: Touchless (infrared)
- Operating temperature: -20°C to 55°C (14°F to 131°F)
- Operating humidity: 0–95%
- Detection range: 3–20 cm (adjustable)
- Opening time: 0.3–30 s (adjustable)
- LED indicator:
- Blue LED: Power on (standby mode)
- Green LED: Power on (motion detected)
- Dimensions : 80 x 32 x 23 mm
- Weight: 126 g
The set includes
- 1x Exit Button EB-1406
- 1x Set of mounting accessories
- 1x User Manual
The Polish user manual is available for download as an attachment. You'll find it above or below our product description .
